Engineered Davit Anchors

X500: Rotatable 360-Degree Overhead Anchor

Meet the Malta Dynamics X500 Free-Standing Anchor, a one stop shop for your rotatable 360-degree overhead anchor point for fall protection.

This steel construction with tough powder coat finish is proudly made in the USA. The X500 is extremely compact, measuring in at under 5 square feet of floor space, and offers 5,950 pounds of anchor weight.

We’ve tested the X500 to meet the strict requirements of OSHA, so you can work with peace of mind knowing we’ve evaluated the design thoroughly. The unit provides an overhead anchor point up to 20’ for one worker with 30-degrees of working radius. The X500 comes equipped with forklift pockets for easy mobility and a multi-position boom lock to provide a fixed position arm when needed.

The X500 is perfect for loading and unloading situations, inside or outside. Because the free-standing fall protection system always keeps the anchor point above the worker, it significantly reduces the possibility of a hazardous swing fall.

We’ve engineered the X500 with you in mind, so easy assembly is a must. The unit comes with minimal field set-up; the parts of this steel construction simply bolt together and features built-in leveling jacks to accommodate any jobsite.

Meet with an XSERIES expert to discuss your fall protection needs. Schedule a meeting today.
Weight 5950 lbs.
Max. Working Height 20' (6.7m)
Width 6'1" (1.9m)
Length 13' (3.96m)
Max. Anchor Point Capacity 310 lbs.
Max. Allowable Users 1

X525: Floor Mounted Anchor

Meet the Malta Dynamics X525 Floor Mounted Anchor. This XSERIES model is ideal for applications that require a permanently installed rotatable 360-degree overhead anchor point for fall protection. Applications like off-loading trucks, securing truck loads, machine maintenance and manufacturing, industrial maintenance, and rail yards are just some of the many examples that the X525 would be an ideal solution for.

The X525 meets ANSI Z359.6-2016 and 2019 IBC and is compliant with OSHA’s fall protection rules.

This fall protection system can be installed inside or outside by first installing the 3’8” footer directly into the ground and then attaching the rotatable mast attachment. The set-up is quick and easy and with the proper maintenance, can safely provide overhead anchorage for years of service.

The X525 provides overhead fall protection, up to 25’ in the air, for one worker with a weight capacity of 130-310 lbs. This steel construction with tough powder coat finish is proudly made in the USA, and the entire unit weighs approximately 1,784 lbs. The X525 is extremely compact and especially suited for tight working spaces where other fall protection solutions might not safely fit.

We’ve tested the X525 to meet the strict requirements of OSHA, so you can work with peace of mind knowing we’ve evaluated the design thoroughly and you worker can operate safely within a radius of 30 degrees. The overhead arm of the X525 reaches out an impressive 9’7” over the fall hazard and can rotate with the worker as they move.

Meet with an XSERIES expert to discuss your fall protection needs. Schedule a meeting today.

Weight 1784 lbs.
Max. Working Height 25' (7.62m)
Reach 9'7" (2.92m)
Max. Anchor Point Capacity 310 lbs.
Max. Allowable Users 1

X550: Truck Counterweighted Anchor

Introducing the Malta Dynamics X550 Mobile Overhead Anchor Truck Counterweighted Model. This XSERIES model is a variation of our original X500 free standing mobile anchor. The X550 provides a fixed overhead anchor point for one worker up to 22’ in the air and uses the weight of your truck as a counterweight.

The X550 is easy to operate and takes up less than 7.5’x7.5’ of floor space. To set up the X550, simply place the unit in the desired working position and then drive your rear truck wheels over the built in beveled base plate until they are centered in the middle of the base plate. Once your truck is securely in place, you are ready to attach your personal fall arrest system and get to work.

Like all the models in the XSERIES mobile fall protection family, the X550 is proudly made in the USA, and features a completely steel body that is power coated with the highest quality surfacing.

The X550 meets ANSI Z359.6-2016 and 2019 IBC and is compliant with OSHA’s fall protection rules.

This entire fall protection system weighs in at just 2,271 lbs. and provides reliable overhead anchorage for a worker weighing from 130-310 lbs. The overhead arm on the X550 reaches out 7’6” and workers can operate safely within a 30 degree radius.

The X550 is ideal for applications including, but not limited to, securing truck loads, accessing the top of tanker trucks, and maintaining RVs at a dealership.

Meet with an XSERIES expert to discuss your fall protection needs. Schedule a meeting today.

Weight 2271 lbs.
Max. Working Height 22' (6.71m)
Width 7'5" (2.26m)
Reach 7'6" (2.29m)
Max. Anchor Point Capacity 310 lbs.
Max. Allowable Users 1
